Prosense PQ Series Gas Detectors
Prosense “PQ” Series fixed gas detectors have been designed and developed for the demanding conditions of the industry in order to perform continuous measurement of combustible, toxic, asphyxiate, and VOC gases in the environment.
With ATEX / IECEx, SIL2 certifications, EN 60079-29: 1 performance approval and high ingress protection class, it has proved its suitability for harsh environmental conditions.
PID, Pellistor, Electrochemical, Infrared, Semiconductor sensors employed PQ provides excellent output in LEL, ppm,ppb and VOL ranges.
To provide the best solution to evolving industry conditions and customer demands, the PQ Series is classified as PQD (With Display) and PQN (Without Display).
| Sensor Technology | Pellistor, Infrared, Electrochemical, PID, Semiconductor |
| Output Signal | 4-20mA and Modbus RS485 |
| Sensor Warm-Up | 60sec |
| Response Time(T90) | Sensor dependent |
| Accuracy | %1 |
| Operating Temperature | -40°C ~ +70°C |
| Humidity | 0~ 100%RH Non-Condensing |
| Input | Min 10VDC – Max 32VDC – Nominal 24VDC |
| Display | 128×64 Graphic OLED 5 LED indicator for detector status |
| Event Logging | Records alarm, fault and maintenance events up to 250 logs |
| Power Consumption | Max. 4W |
| Relay Outputs | 2 Alarms (Programmable) and 1 Fault (All relays are NO/NC adjustable) |
| IP Rating | IP65/IP66 |
| Junction Box | Epoxy Painted Die-Cast Aluminum / 316 Stainless Steel |
| Sensor Head | 316L Stainless Steel |
| Dimensions/Weight | 196,96×145,99x112mm / 2100gr |
| ATEX Marking | II 2G Ex db IIC T6 Gb II 2G Ex mb db IIC T6 Gb I M2 Ex db I Mb |
| Hazardous Class | Zone 1 – Zone 2 – M2 |
| Certificates | ExVeritas 18 ATEX 0371X IECEx EXV 18.0021X FTZU 18 ATEX 0086 IEP12 ATEX 6118X SIL2 |
| Standards | IEC EN 60079-0 IEC EN 60079-1 IEC EN 60079-18 IEC EN 60079-29- |
